Tactical Canopy Rack

The Tactical Cab Rack is designed for most Canopy’s

The Tactical Rack is made locally in Abbotsford BC. The material is water jet cut from 3/16 Aluminum which provides the highest quality finish. The rack then goes to sandblasting to remove imperfections. And then finally finished with a light matt black textured finish.

The rack comes standard with 7x 1”x2” Aluminum Extrusions with T-Slot channels on all six sides to provide for maximum mounting capability.

This is a No drill rack and bolts right into the factory track locations. Must have the following roof tracks installed

• Thule Tracks
• Yakima tracks
• Rhino Rack

Standard Features:

• 3/16 Water Jet Aluminum Sideplates Black Powdercoat
• 7 Total 1”x2” Black Anodized T slot extrusion bars
• 4x Mounting Podium feet
• Stainless Steel Mounting Hardware
• Black Stainless hardware for Extrusions

Rack Dimensions:

• Overall Length 70”
• Width 47.25”
• Overall Height Added 3”
• Space under extrusions 1.25”
• Weight 40lbs
• Carrying Capacity’s ( Static 500Lbs / Dynamic 300Lbs)

*Current lead times are between 3-5 weeks
